AK-RAMON TS-170 CUT – Tray Sealer

Manual tray sealer AK-RAMON TS-170 CUT

  • Manual tray sealing machine totally manufactured in AISI 304 stainless steel.
  • Die sets in anodised aluminium.
  • Manual tray sealing machine.
  • Perimetral cutting with the shape of the tray.
Lead Time Estimated Delivery: 20/12/2023
(UK Shipping Only)
£2,427.45 (exc VAT) £2,912.94 (inc VAT)
Add To Quote

Features & Benefits

  • Digital panel with sealing temperature regulator (0°-230° C).
  • Ergonomic and robust model.
  • Easy mold change, molds are interchangeable in a few seconds.
  • Easy and fast heating of the machine.
  • It allows to work with different types of tray materials, PP, PET, ALUMINIUM…
  • Voltage: 220 V/ 1ph/ 50 Hz.
  • Maximum sealing surface: 320×260 mm.
  • Film roll width: 360 mm.
  • Power: 1500 W.
  • Includes 320×260 mm die set.

Standard molds

  • 1/4 GN (260×160 mm).
  • Any type and shape of die set can be manufactured according to the customer trays.

Technical Specs

Food thermosealing is a method of closing trays by applying pressure and heat to a plastic film using tray sealers such as those produced by AK RAMON. It is also known as heat sealing and serves to isolate the products stored in the container from air and other external agents such as bacteria and microbes.

The main characteristics of a good manual tray sealer are that it can be adapted to all types of heat sealable containers and guarantees rapid heating of the Teflon plate thanks to a power that must be at least 900 W to reach 230º C.

There are many advantages to using heat sealing for food preservation:

It offers a more attractive and hygienic presentation of the food for the consumer.
Heat-sealing allows food to be kept in excellent condition, preventing it from being crushed.
The use of heat-sealing facilitates the storage of food in suitable plastic containers or heat-sealable trays.

It allows large quantities of food to be packaged in short periods of time.

It can be used in any type of business such as butchers, fishmongers, delicatessens, fruit shops, supermarkets, catering companies, take away and restaurants.
